Fundamentals of Applied Electromagnetics

Bridging the gap between circuits and electromagnetics.

Widely acclaimed in the field, this authoritative text bridges the gap between circuits and electromagnetics material. Fundamentals of Applied Electromagnetics begins coverage with transmission lines, leading students from familiar concepts into more advanced topics and applications. The 8th Edition builds on the core content and style of previous editions, retaining the student-friendly approach and hands-on simulation modules that help students develop a deeper understanding of electromagnetic concepts and applications. Enhanced graphs and illustrations and an expanded scope of topics in the Technology Briefs, establish additional bridges between electromagnetic fundamentals and their countless engineering and scientific applications.

Contents:
Chapter 1. Introduction: Waves and Phasors
1-1 Historical Timeline
1-2 Dimensions, Units, and Notation
1-3 The Nature of Electromagnetism
TB1 LED Lighting
1-4 Traveling Waves
1-5 The Electromagnetic Spectrum
1-6 Review of Complex Numbers
TB2 Solar Cells
1-7 Review of Phasors
Chapterr 2. Transmission Lines
2-1 General Considerations
2-2 Lumped-Element Model
2-3 Transmission-Line Equations
2-4 Wave Propagation on a Transmission Line
2-5 The Lossless Microstrip Line
2-6 The Lossless Transmission Line: General Considerations
2-7 Wave Impedance of the Lossless Line
2-8 Special Cases of the Lossless Line
TB3 Microwave Ovens
2-9 Power Flow on a Lossless Transmission Line
2-10 The Smith Chart
2-11 Impedance Matching
2-12 Transients on Transmission Lines
TB4 EM Cancer Zappers
Chapter 3. Vector Analysis
3-1 Basic Laws of Vector Algebra
3-2 Orthogonal Coordinate Systems
3-3 Transformations between Coordinate Systems
3-4 Gradient of a Scalar Field
TB5 Global Positioning System
3-5 Divergence of a Vector Field
3-6 Curl of a Vector Field
TB6 X-Ray Computed Tomography
3-7 Laplacian Operator
Chapter 4. Electrostatics
4-1 Maxwells Equations
4-2 Charge and Current Distributions
4-3 Coulombs Law
4-4 Gausss Law
4-5 Electric Scalar Potential
TB7 Resistive Sensors
4-6 Conductors
TB8 Supercapacitors as Batteries
4-7 Dielectrics
4-8 Electric Boundary Conditions
TB9 Capacitive Sensors
4-9 Capacitance
4-10 Electrostatic Potential Energy
4-11 Image Method
Chapter 5. Magnetostatics
5-1 Magnetic Forces and Torques
5-2 The BiotSavart Law
5-3 Maxwells Magnetostatic Equations
5-4 Vector Magnetic Potential
TB10 Electromagnets
5-5 Magnetic Properties of Materials
5-6 Magnetic Boundary Conditions
5-7 Inductance
5-8 Magnetic Energy
TB11 Inductive Sensors
Chapter 6. Maxwells Equations for Time-Varying Fields
6-1 Faradays Law
6-2 Stationary Loop in a Time-Varying Magnetic Field
6-3 The Ideal Transformer
6-4 Moving Conductor in a Static Magnetic Field
6-5 The Electromagnetic Generator
6-6 Moving Conductor in a Time-Varying Magnetic Field
6-7 Displacement Current
6-8 Boundary Conditions for Electromagnetics
6-9 ChargeCurrent Continuity Relation
6-10 Free-Charge Dissipation in a Conductor
TB12 EMF Sensors
6-11 Electromagnetic Potentials
Chapter 7. Plane-Wave Propagation
7-1 Time-Harmonic Fields
7-2 Plane-Wave Propagation in Lossless Media
7-3 Wave Polarization
TB13 RFID Systems
7-4 Plane-Wave Propagation in Lossy Media
TB14 Liquid Crystal Display (LCD)
7-5 Current Flow in a Good Conductor
7-6 Electromagnetic Power Density
Chapter 8. Wave Reflection and Transmission
8-1 Wave Reflection and Transmission at Normal Incidence
TB15 Lasers
8-2 Snells Laws
8-3 Fiber Optics
8-4 Wave Reflection and Transmission at Oblique Incidence
TB16 Bar-Code Readers
8-5 Reflectivity and Transmissivity
8-6 Waveguides
8-7 General Relations for E and H
8-8 TM Modes in Rectangular Waveguide
8-9 TE Modes in Rectangular Waveguide
8-10 Propagation Velocities
8-11 Cavity Resonators
Chapter 9. Radiation and Antennas
9-1 The Hertzian Dipole
9-2 Antenna Radiation Characteristics
9-3 Half-Wave Dipole Antenna
9-4 Dipole of Arbitrary Length
9-5 Effective Area of a Receiving Antenna
9-6 Friis Transmission Formula
TB17 Health Risks of EM Fields
9-7 Radiation by Large-Aperture Antennas
9-8 Rectangular Aperture with Uniform Aperture Distribution
9-9 Antenna Arrays
9-10 N-Element Array with Uniform Phase Distribution
9-11 Electronic Scanning of Arrays
Chapter 10. Satellite Communication Systems and Radar Sensors
10-1 Satellite Communication Systems
10-2 Satellite Transponders
10-3 Communication-Link Power Budget
10-4 Antenna Beams
10-5 Radar Sensors
10-6 Target Detection
10-7 Doppler Radar
10-8 Monopulse Radar
Appendix A: Symbols, Quantities, and Units
Appendix B: Material Constants of Some Common Materials
Appendix C: Mathematical Formulas
Appendix D: Fundamental Constants and Units
Appendix E: Answers to Selected Problems
Bibliography
Index
Tables for Reference
